DS Continuous bucket conveyor

DS Continuous bucket conveyorDS Continuous bucket conveyorDS Continuous bucket conveyor

DS Continuous bucket conveyor

Item No.: IFA-KYC204756
DS continuous bucket conveyor (bucket machine for short) is independently R&D according to the advanced technology from abroad. It is suitable for horizontally or tiltable conveying various powder and massive bulk material,

Introduction:

DS continuous bucket conveyor (bucket machine for short) is independently R&D according to the advanced technology from abroad. It is suitable for horizontally or tiltable conveying various powder and massive bulk material, such as cement, clinker, slag, iron ore, limestone, coke, etc. Its temperature resistance and reliability are better than the chain plate conveyor, belt conveyor and vibrating conveyor, etc., and it  can save 20% to 50% of the power than the currently widely used chain plate conveyor.

Application:

DS continuous bucket conveyor can be promoted to use in the building, metallurgy, coal, chemical, electric power industry and other departments of the national economy.

Features:

1. The temperature of the materials can reach 350 °C if the machine is made of general structural carbon steel.

2. The temperature of the materials is allowed to reach 600 °C

3. The blockiness size is up to 200mm if the machine is made of general heat-resistant steel.

                                                   Technical Parameter:

Model

Bucket width(mm)

Flange height (mm)

Rated capacity(α≤25°)m3/h

Speed (m/s)

0.15

0.20

0.25

0.30

DS400

400

160

29

39

49

59

DS540

540

160

40

53

68

80

DS640

640

200

59

79

99

119

640

250

74

99

124

149

DS800

800

250

93

124

156

187

800

300

112

150

187

225

DS1000

1000

300

140

187

234

281

1000

350

164

219

274

329

DS1200

1200

350

197

236

329

392

DS1400

1400

350

230

307

384

460

DS1600

1400

350

263

350

439

526
