DTII stationary belt conveyor

Item No.: IFA-WBI544456
DTII stationary belt conveyor is universal series products, and can be widely used in metallurgical, mining, coal, ports, power stations, building materials, chemical industry, light industry, petroleum and other various sectors.

Introduction:

DTII stationary belt conveyor is universal series products, and can be widely used in metallurgical, mining, coal, ports, power stations, building materials, chemical industry, light industry, petroleum and other various sectors. The standalone or more units conveying material conveying system synthesis can be used for 500 - loose density of 2500Kg/m3 material into items scattered w.

DTII type stationary belt conveyor applicable work environment for the average temperature 25 °C -- 40. For work in the special environment of belt conveyor, such as the requirement has heat resistance, cold resistance, waterproof, anticorrosive, explosion, fire retardant conditions, shall adopt corresponding protective measures.

DTII type stationary belt conveyor are designed according to component series. Designers can provide transportation process request, according to the different terrain, conditions

Application:

DTII stationary belt conveyor is universal series products, and can be widely used in metallurgical, mining, coal, ports, power stations, building materials, chemical industry, light industry, petroleum and other various sectors.

Features:

1.Can automatic control

2.The temperature is below 65 degrees in conveying material

3.Adapt conveying different materials

Technical parameters:

beltwidth

B

(mm)

belt speedV(m/s)

the largest block of material

0.8

1.0

1.25

1.6

2.0

2.5

3.15

4

(4.5)

5.0

(5.6)

6.5

lv,m3/h

500

69

87

108

139

174

217

--

--

--

--

--

--

100

650

127

159

198

254

318

397

--

--

--

--

--

--

150

800

198

248

310

397

496

620

781

--

--

--

--

--

200

1000

324

405

507

649

811

1014

1278

1622

--

--

--

--

300

1200

--

593

742

951

1188

1486

1872

2377

2674

2971

--

--

350

1400

--

825

1032

1321

1652

2065

2602

3304

3718

4130

--

--

350

1600

--

--

--

--

2186

2733

3444

4373

4920

5466

6122

--

350

1800

--

--

--

--

2795

3494

4403

5591

6291

6989

7829

9083

350

2000

--

--

--

--

3470

4338

5466

6941

7808

8676

9717

11277

350

2200

--

--

--

--

--

--

6843

8690

9776

10863

12166

14120

350

2400

--

--

--

--

--

--

8289

10526

11842

13158

14737

17104

350
