Product description:

Air cushion conveyor is a new generation of long-distance transmission equipment. Compared with common belt conveyor, it has the features of high efficiency; large delivery value and the belt would not run out. This product has simple structure, less wearing parts. Its maintenance cost can be saved over 50%. It can be applied to convey bulk materials and bags, but also to convey chemicals and medicines, the toxic materials in closed circulation gas chamber. It is widely used in metallurgy, coal, chemical, pharmaceutical, food, grain and feed industry and ports and terminals

Application:

It is an ideal machine for conveying in long distance and large capacity, which can be used in the following industry: food & oil, port, coal, chemical engineering, metallurgy, building material, electric power etc.

Feature:

1.Stable operation;safe and reliable

2.low power consumption

3.Long service life

4.low maintenance

5.Stable operation; safe and reliable; low power consumption

6.Long service life; low maintenance cost

7.Easy to install

8.High work efficiency

Technical parameters:

Type

Tape width mm

Transmission capacity (t/h)

The maximum transmission distance (m)

Speed(m/s)

Maximum angle of inclination

QJG500

500

40-100

200

1.2-4.5

0-30°

QJG650

650

100-220

250

QJG800

800

220-500

300

QJG1000

1000

500-800

500

QJG1200

1200

800-1400

600

QJG1400

1400

1400-1800

650

QJG1600

1600

1800-2200

650

QJG1800

1800

2200-2500

650
















Date
Type

B

A

H

H1

H2

S1

S2

L

L1

L2

φ

QJG

500

500

870

800

580

210

1000

1000

800

840

950

89

QJG

650

650

1020

800

560

230

1000

1150

960

1130

1150

89

QJG

800

800

1220

800

550

240

1100

1410

1180

1120

1340

89/108

QJG

1000

1000

1440

1000

690

300

1100

1610

1410

1240

1440

108

QJG

1200

1200

1690

1000

660

330

1100

1860

1660

1430

1480

133

QJG

1400

1400

1890

1000

640

350

1100

2120

1860

1420

1520

133/159

QJG

1600

1600

2100

1100

750

400

1300

2220

2060

1620

1720

159

QJG

1800

1800

2320

1200

750

400

1300

2220

2060

1620

1720

159
